Replaces OEM General Pump TC1506GUI
- Crankcase oil capacity 11.8 oz.
- Flanged for direct couple to gasoline engines; 3/4" hollow shaft
- Flooded pump dimensions 10.4" x 8" x 7.7"
- Gauge port 1/8" maximum inlet required
- Inlet port thread 1/2"-14 BSP-F and Discharge port thread 3/8"-19 BSP-F
- Manufacturer warranty applies
- Maximum fluid temperature: 165 F
- Maximum inlet pressure: 125 PSI
- Premium built-in trapped pressure unloader on left side of manifold with an exclusive lifetime warranty
- TC Series 60, Triplex plunger pump, SAE J609A
- Bore Size0.591"
- Gallons Per Minute2.600
- HP7.210
- Made ByAn OEM Supplier
- PSI2700
- TypeHorizontal Gas Flanged
